Bloodline 20" BMX Race Frame

(3)
Item sold out. Cannot be delivered

Description

The Bloodline race BMX frame from Staats is crafted from 7005 aluminium, ideal for delivering a stiff, lightweight, and robust BMX racing experience. It features a Nockewelle integrated Quick Release seat clamp and dropslot hangers compatible with any 3/8" (10mm) rear wheel axles.

This racing frame is designed for Euro bottom brackets and accommodates 1" integrated headsets (available separately).

Notice: Staats have created an indentation in the chainstay area to allow additional space for the chain and chainring.

Model specifications

ModelFrame Top TubeWeightSeat clampHeadset typeHeadtube angle
Junior - White18.5"2lbsIntegrated, Quick release, 22.2mmIntegrated 1"71°
Junior - Silver18.5"2lbsIntegrated, Quick release, 22.2mmIntegrated 1"71°
Junior - Pink18.5"2lbsIntegrated, Quick release, 22.2mmIntegrated 1"71°
Expert - Blue19.5"2lbsIntegrated, Quick release, 22.2mmIntegrated 1 1/8", Integrated 1"72°
Expert - Silver19.5"2lbsIntegrated, Quick release, 22.2mmIntegrated 1 1/8", Integrated 1"72°
Expert XL - Yellow20.25"2lbsIntegrated, Quick release, 27.2mmIntegrated 1 1/8", Integrated 1"73°
Expert XL - Blue20.25"2lbsIntegrated, Quick release, 27.2mmIntegrated 1 1/8", Integrated 1"73°
Expert XL - Silver20.25"2lbsIntegrated, Quick release, 27.2mmIntegrated 1 1/8", Integrated 1"73°
Expert XL - Black20.25"2lbsIntegrated, Quick release, 27.2mmIntegrated 1 1/8", Integrated 1"73°
Pro - Blue20.75"2lbsIntegrated, Quick release, 27.2mmIntegrated 1 1/8"74°
Pro - Black20.75"2lbsIntegrated, Quick release, 27.2mmIntegrated 1 1/8"74°
Pro - Silver20.75"2lbsIntegrated, Quick release, 27.2mmIntegrated 1 1/8"74°
Pro XL - Silver21.25"2lbsIntegrated, Quick release, 27.2mmIntegrated 1 1/8"74°
Pro XL - Italian Red-----
Pro XL - Black21.25"2lbsIntegrated, Quick release, 27.2mmIntegrated 1 1/8"74°
Pro XL - Yellow21.25"2lbsIntegrated, Quick release, 27.2mmIntegrated 1 1/8"74°
Pro XL - Blue21.25"2lbsIntegrated, Quick release, 27.2mmIntegrated 1 1/8"74°
Pro XXL - Black22"2lbsIntegrated, Quick release, 27.2mmIntegrated 1 1/8"74°
Pro XXL - White22"2lbsIntegrated, Quick release, 27.2mmIntegrated 1 1/8"74°
Pro XXL - Blue22"2lbsIntegrated, Quick release, 27.2mmIntegrated 1 1/8"74°
Pro XXL - Silver22"2lbsIntegrated, Quick release, 27.2mmIntegrated 1 1/8"74°
Pro XXXL - Silver-----

Specifications

BMX Discipline:
Race BMX
Frame material:
Aluminium, 7005
BMX Brake Included:
V-brake not included
Chain Tensioners:
No
Bottom Bracket:
European (EURO)
